Keyboard Wedge
USB
RS485 (IBM)
Bluetooth
Radio
1D
industrial
| Performance | Scan Pattern | Single bright aiming line |
| Scan Angle | Horizontal 35° | |
| Scan Speed | 547 scans per second | |
| Motion Tolerance | 25 in./ 63.5 cm per second | |
| Light Sources | LED Class 1 device 617nm (amber) | |
| Wireless Connectivity | Radio | Bluetooth v2.1 Class 2 Radio |
| Data Rate | 3.0 Mbit/s (2.1 Mbit/s) Bluetooth v2.1 | |
| Radio Range* | 330 ft./100 m (line of sight) | |
| Physical | Dimensions |
3.84 in. H x 2.75 in. W x 7.34 in. L |
| Weight | 7.9 oz./224 grams | |
| Cradle Interface | RS232, RS485 (IBM), USB, Keyboard Wedge | |
| Color | Black; White | |
| Battery | Rechargeable replaceable battery with ‘green sustainability’ | |
| User Environment | Ambient Light Immunity | Max 108,000 lux |
| Operating Temp. | 32° F to 122° F/ 0° C to 50°C | |
| Storage Temperature | -40° F to 158° F/-40° C to 70° C | |
| Humidity | 5% to 85% RH, non-condensing | |
| Drop Specification |
Over 100 drops at 5 ft./1.5 m at room temperature; survives 6ft./1.8 m drops to concrete |
|
| Environmental Sealing | IP53; Gasket sealed housing withstands dust and can be sprayed clean | |
| 3 mil | Minimum resolution | |
| 4 mil | 4-10 in./10.2-25.4 cm | |
| 5 mil | 3-13 in./7.6-33 cm | |
| 7.5 mil | 1.5-19 in./ 3.8-48.3 cm | |
| 13 mil (100% UPC-A) | 1-31 in./2.5-78.7 cm | |
| 20 mil | 1-42 in./2.5-106.7 cm | |
| 26 mil (200% UPC-A) | 3-55 in./7.6-140 cm | |
| 100 mil (paper) | >20 ft./6 m |
